Description:

The Raptor® XD is the ideal zero-turn for homeowners with up to five acres of property. The up to 24hp Kawasaki® engine and 60-inch deck option makes the XD a premium lawn mower in the residential zero-turn category. Like all Raptors, we’ve spent decades and thousands of hours perfecting our durable fabricated decks that provide a crisp, clean cut-quality. Raptor XDs are backed by a 3yr / 300hr limited warranty.

Features:

Welded Steel Deck

• Welded fabricated steel deck helps add durability and can extend the mower's life.

Wider Stance

• Designed to provide ample room, adding to the comfort for the operator.

SmoothTrak Steering

• Precision control designed to help trim and maneuver easily around obstacles.

Bolstered Seat

• Helps provide a comfortable ride with armrests and airflow to the back.

Rubber Floor Mat

• Helps provide comfort by minimizing vibration on the operator's feet. Standard on all Raptor models.

Fabricated Frame

• Continuous one-piece 1½ inch by 3 inch welded tubular frame.

Foot-Operated Deck Lift

• Easily adjust the deck height between 1.5" - 4.5".

Easy to Service

• Flip-up seat pan, removable floor pan, vented pulley covers.

Exclusive BigBite Rear Tires

• Designed in collaboration with the tire manufacturer for improved performance.

Kawasaki® Power

• Powered by a V-Twin Kawasaki® Engine.

Specification:

Engine

• Model: Kawasaki FR651
• Horsepower: 21.5 HP
• Displacement: 726cc
• Cooling: Air Cooled
• Warranty: 3 Year Warranty

Transmission

• Type: Dual Hydrostatic
• Model: Hydro-Gear ZT-2800®
• Warranty: 3 Year Warranty

Fuel Capacity

• 3 gallons

Ground Speed

• Forward: Up to 7.5 mph

Cutting Deck

• Width: 48 inches
• Height Range: 1.5" to 4.5"
• Lift System: Foot-Operated Deck Lift

Wheels

• Front Tires: 13 x 6.5 inches
• Rear Tires: 20 x 8-10 inches, BigBite™

Dimensions

• Weight: 627 lbs
• Length: 69.3 inches
• Width: 43.7 inches
• Height: 52.5 inches

Seat

• Bolstered high-back seat with armrests and built-in lumbar support

Warranty

• 3 Year/300 hour residential

Bagging System (Optional)

• Type: 2-bag, non-powered
• Capacity: 5.4 bushel

Overall Dimensions

• Length: 91.4 inches
• Width: 63.5 inches
